2018 Ford Mustang Shelby GT350 — Matte Bronze Center with Gloss Black Beadlock-Style Ring Forged Monoblock (19×11 Square

Engineering Notes

XINGTU's engineers want to be clear on one point up front: the gloss black outer ring on this wheel is a cosmetic/decorative element in beadlock style — it is NOT a true functional beadlock ring (which would require DOT-off-road certification and a specific ring-clamp tire retention system). All structural load — cornering, braking, impact, and the 5.2L Voodoo V8's torque — is carried by the forged 6061-T6 monoblock face and barrel. The black ring is bolted on for the show/off-road aesthetic only, so the structural rating never depends on it.

The forged structure itself is a true monoblock: XINGTU's engineers cut the multi-spoke face and barrel from one continuous forged 6061-T6 billet, preserving unbroken grain flow from the hub to the rim for maximum fatigue strength. This matters on the GT350 — its flat-plane-crank V8 revs to 8,250 rpm and puts significant rotational stress into the wheel; the monoblock structure holds a 750 kg-per-wheel load rating at just 12.5 kg net, keeping unsprung mass low enough to preserve the car's razor-sharp turn-in.

XINGTU's engineers also verified the 15×32×60° taper lug seat against the Ford Mustang OEM standard — correct seat geometry is essential for proper clamping torque and is a direct safety factor. The 70.5 mm bore is machined hub-centric to the Ford S550 platform, so the wheel rides on the hub, not the studs. The square 19x11 fitment with staggered offsets (ET26 / ET52) is a classic wide-body Mustang setup: it lets the rear pull further inboard while the front pushes outboard to match the arch geometry — same wheel width both ends, but positioned differently in the arches.

From Design to Delivery

• CMM dimensional inspection (PCD / CB / runout)
• Dynamic balancing on every wheel
• Forged 6061-T6, hub-centric machining verified
• Taper lug seat profile verified against Ford Mustang OEM standard
• Black outer ring fitment & fastener torque checked before packing
• Matte bronze powder coat cure & consistency verified

Result

Compare the studio render on the left with the finished wheels photographed in-plant on the right—concept and reality match precisely. The matte antique bronze multi-spoke face reads as machined-aluminum warmth up close, while the gloss black beadlock-style outer ring delivers a dramatic show/off-road-inspired frame around the spoke geometry. Fasteners around the ring are visually integrated as decorative accents. XINGTU-branded center cap installed on the finished wheels—publish-ready. True forged monoblock, 750 kg-per-wheel load-rated, and bolt-on ready to any 2015+ S550 Mustang platform.

Building a Shelby GT350, GT500, Mach 1, or any S550 / S650 Mustang?

XINGTU forges monoblock, 2-piece, and 3-piece constructions to your exact fitment—including cosmetic beadlock-style rings, custom colors, and finish options.

MOQ 1 set, DDP worldwide. Send your specs for a free fitment check.

• Luxury & Premium Vehicles: Designed for luxury sedans, SUVs, and premium vehicles requiring enhanced appearance, refined styling, and OEM-level fitment precision.
• Performance & Track Builds: Optimized for performance vehicles where lightweight construction, structural strength, brake clearance, and handling response are critical.
• Custom Tuning Projects: Fully customizable in diameter, width, offset, bolt pattern, finish, and design to meet unique vehicle builds and individual styling requirements.
• Classic & Restomod Vehicles: Modern forged wheel solutions for classic cars, combining advanced engineering with timeless styling while preserving the vehicle’s original character.
• Show Cars & Exhibition Builds: Premium forged wheels featuring unique designs and high-end finishes, created for show-quality vehicles demanding exceptional visual impact.
• SUV & Off-Road Customization: Engineered for high-performance SUVs and customized builds requiring durability, higher load capacity, and distinctive styling.
• OEM Replacement & Upgrade: Precision-engineered replacement solutions that maintain factory-level fitment while improving appearance, performance, and driving confidence.
• Automotive Brands & Tuning Shops: Reliable custom wheel solutions for automotive brands, tuning shops, and distributors, supporting prototype development, small-batch production, and long-term supply partnerships.

1. Can you customize wheels based on my vehicle specifications?
A: Yes. We provide full customization based on vehicle model, wheel size, width, offset, bolt pattern, center bore, brake clearance, and design requirements.

2. What information do you need before starting a custom wheel project?
A: We usually require your vehicle make, model, and year, along with wheel diameter and width, bolt pattern (PCD), offset (ET), brake clearance requirements, and preferred wheel design and finish details.

3. What materials are used for forged wheels?
A: Our forged wheels are manufactured using high-strength aerospace-grade aluminum alloys, providing excellent strength-to-weight performance.

4. What finishes are available?
A: We offer a wide range of finish options, including brushed finish, polished finish, gloss black, matte finish, custom color coating, and two-tone finishes to meet different styling requirements.

5. What is the typical production lead time?
A: Production time depends on design complexity, quantity, and finishing requirements. A typical custom project usually takes 30–45 days, including engineering confirmation, machining, QC, and delivery preparation.

6. Do you support small quantity orders?
A: Yes. We support prototype development, sample orders, and small-batch production for tuning shops, distributors, and automotive brands.
